Ethernet Module USR-TCP232-T1 Pin Product Overview :
USR-TCP232-T1/S1 is a newly launched module by Youlian that can quickly realize transparent transmission of network port and serial port data.
All data protocol conversions are processed internally.
Users only need simple configuration to realize serial port data to the network. terminal transmission.
|
CLASSIFICATION
|
PARAMETER
|
VALUE
|
|
Power supply parameters
|
Operating Voltage
|
VCC: 3.15～3.45 V; VDD: 5.0～7.0V
|
|
Working current
|
150mA@3.3V
|
|
Hardware interface
|
Network port specifications
|
RJ45, 10/100Mbps, cross-connect adaptive
|
|
Serial port standard
|
1 channel TTL-3.3 level signal
|
|
Serial baud rate
|
300-921.6K (bps)
|
|
data bits
|
7, 8
|
|
Check Digit
|
When the data bit is 7 bits, Odd, Even, Mark and Space are supported.
When the data bit is 8 bits, None, Odd, and Even are supported.
|
|
Product Size
|
Specifications (L*W*H)
|
55.0×22.6×23.4mm
|
|
Packaging method
|
Pin package
|
|
working environment
|
Operating temperature
|
-40～85℃
|
|
storage temperature
|
-40～105℃
|
|
Working humidity
|
5%～95% RH (no condensation)
|
|
Storage humidity
|
5%～95% RH (no condensation)
|
|
Software function
|
Network protocol
|
IP, TCP/UDP, ARP, ICMP, IPV4, HTTP
|
|
IP acquisition method
|
Static IP, DHCP
|
|
DNS
|
Support, customizable DNS server address
|
|
User configuration
|
Software configuration, web page configuration, AT command configuration
|
|
Operating mode
|
TCP Server/TCP Client/UDP Server/UDP Client/Httpd Client
|
|
Modbus gateway
|
Supports mutual conversion between ModbusRTU and ModbusTCP protocols;
Supports automatic polling of instructions, up to 5, optional transparent transmission/JSON protocol reporting
|
|
TCP Server connection
|
Supports up to 16 TCP connections (customizable)
|
|
network cache
|
Send: 6Kbyte; receive: 6Kbyte
|
|
Serial buffer
|
Receive: 1Kbyte
|
|
average transmission delay
|
<10ms
|
|
Supporting software
|
Virtual serial port, human cloud, parameter setting software, WEB page
|
|
Packaging mechanism
|
4-byte packing time, 400-byte packing length
|
|
Special feature
|
RFC2217-like, short link, timeout and no data restart
|
|
other
|
Protection level
|
EMC level 2 (including static electricity, surge, electrical fast pulse group)
|
