Displays, Smart LCD Module
DWIN 4.3 Inch HMI UART LCM DMG48270C043_03WTC
SKU: DMG48270C043_03WTC
₹2,525.20
₹2140 + 18% GST
incl. GST
Availability: In Stock (3 units)
Estimated Delivery: Usually ships within 2-3 business days
For bulk orders or B2B inquiries, email us: sales@empere.in
- Part Number : DMG48270C043_03WTC
- Size : 4.3inch
- Resolution : 480×272
- Touch Type : Capacitive Touch
- Interface : TTL/CMOS
DWIN 4.3 inch HMI UART LCM DMG48270C043_03WTC :
Features:
- Based on self-designed T5L ASIC,16.7M Colors, 24bit,480*272 pixel, TN TFT LCD;
- No touch screen/Resistive touch screen/Capacitive touch screen ;
- TTL/CMOS; 10Pin_1.0mm socket for power supply and serial communication;
- Multiple download mode: via SD card or on-line serial port;
- Dual Development System: DGUS II/ TA(Instruction set);
- TN View Angle: 70°/70°/50°/70°(L/R/U/D);
- With GUI & OS dual-core, GUI with rich controls. DWIN OS kernel is open to the user for the second-development, via DWIN OS language or KEIL C51
